Singular Platform
- With TracerLynx, data can be automatically imported and stored along with the applicable calculation and project design details.
- TracerLynx is not simply a suite of programs; rather it is a singular, powerful program comprised of a master database providing a single source of truth for all data on a global scale.
- This allows us to reduce errors, quickly modify scope, identify downstream changes and minimize delays to the project’s schedule.
Change Management
- TracerLynx will quickly identify the impact of piping & process changes on existing EHT circuits, which minimizes the negative impacts to your design and construction schedule.
- Filtering all changes that impact EHT designs, while providing visual indicators of changes with colored markers to identify the level of change.
- TracerLynx also evaluates the impact on completed and WIP activities to facilitate early intervention to minimize the impacts of design changes
Heat Mapping Technology
- In the early FEED stage of a project, TracerLynx utilizes a proprietary heat loss algorithm to create Heat Load Densities in 3D, to strategically locate EHT Control Panels first, prior to initiating detailed design.
- This “heat mapping” is a key requirement to begin optimizing power distribution. TracerLynx can import all relevant information into a 3D environment including piping, cable tray, structural beams, buildings, vessels and more.
Power Distribution Savings
- TracerLynx allows designers to choose the optimal location for power connections. In many cases, the average conduit length drops up to 25%, lowering the total installed cost.
- TracerLynx imports data normally plotted in 2D programs, including the project’s structural information, into a state-of-the-art 3D platform to eliminate the design guess-work and deliver the visual design clarity that was previously unattainable.
- Imagine the savings in a large facility with hundreds to thousands of EHT circuits!
Advanced Work Packaging
- TracerLynx supports Advanced Work Packaging (AWP) to aid in labor, equipment & material management throughout the entire project work cycle.
- TracerLynx allocates the work into manageable pieces and provides clients with a complete “work package” outlining everything required to ensure safe and efficient construction work.
- Benefits of AWP include up to a 25% increase in field productivity and a 10% decrease in TIC through site schedule optimization.
- The utilization of TracerLynx AWP for EHT projects results in predictable schedules, reduced site rework and enhanced safety performance.
